Sch40 Aisi 304 316l Seamless Round Pipe Stainless Steel Round Tube

High Light

Sch40 Aisi Seamless Round Pipe
,
300 Series ss round tube
,
316l Seamless Round Pipe
Grade

300 Series
Length

6m 9m 12m OR Customized
Tolerance

±1%
Type

Welded Seamless Steel Pipe
Color

OEM Ss Tube/pipe
Delivery Time

Within 7 Days
Shape Sections

Round, Square, Rectangular
Package

Wooden Cases
Place of Origin

CHINA
Brand Name

NADONG
Certification

ISG SGS
Model Number

316
Minimum Order Quantity

1 Ton
Price

$1000-$1800
Packaging Details

According to customer needs
Delivery Time

15 working days
Payment Terms

L/C, T/T
Supply Ability

1000 ton per month

Sch40 Aisi 304 316l Seamless Round Pipe Stainless Steel Round Tube

Name: Sch40 Aisi 304 316l Seamless Round Pipe Stainless Steel Round Tube
Brand: NADONG
SKU: 316
Price: 1000 USD
Availability: InStock
Rating: 4.9 (175 reviews)

button button

Get Price Contact Now

Factory Price Sch40 Aisi 304 316l Seamless Round Pipe Stainless Steel Round Tube

High strength, good hardenability, good toughness, and small deformation during quenching. At high temperature, it has higher creep strength and permanent strength. It is used for forgings, large gears for locomotive traction, supercharger transmission gears, rear axles, connecting rods with large loads, spring clips; it can also be used for drill pipe joints and fishing tools in oil wells below 2000m.

Specfications

product name	Stainless steel pipe
Grade	201.202.301.302.304.304L.309S.310S.316.316L.321.410.430.430A.440A.440B.440C.904L.2205.2507.2520 ect. Or Customized
Standard	GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Surface	Satin Finish(180#.240#.320#).,Bright Finish(400#,600#,mirror),Mill Finish(2B),Hairline-Finish (HL/Brushed),Ti-gold, Glossy matt,dull and so on.
specifications	Outer diameter	6mm-630mm or customized
	Wall thickness	0.1-30mm or customized
	Length	0.3-15.8m or customized
Technique	Cold rolled	welding or customized
	Hot rolled	seamless
Test and Inspection	Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
Thickness tolerance	±0.05mm

Chemical Composition

Specification	Grade	Chemical Composition(wt%)
Specification	Grade	C	Mn	Ni	Cr	Mo	Ti
ASTMJIS	316L/022Cr17Ni12Mo2	≤0.03	≤2.0	10.0-14.0	16.0-18.0	2.0-3.0	-
JIS	SUS316L	≤0.03	≤2.0	12.0-15.0	16.0-18.0	2.0-3.0	-
ASTMJIS	316Ti/SUS 316Ti	≤0.08	≤2.0	10.0-14.0	16.0-18.0	2.0-3.0	5*(C+N)-0.7

Properties

Spec	Grade	Mechanical Property				Physical Property
Spec	Grade	Y.S (N/MM2)	T.S (N/MM2)	EL (%)	HRB	Specific Heat (J/g℃)	Modulus of Elasticity (KN/mm2)
ASTM/GB	316L/022Cr17Ni12Mo2	≥170	≥485	≥40	≤95	0.5	193
JIS	SUS316L	≥175	≥480	≥40	≤90	0.5	193
ASTM	316Ti	≥205	≥515	≥40	≤95	0.5	200

Sch40 Aisi 304 316l Seamless Round Pipe Stainless Steel Round Tube 0

Sch40 Aisi 304 316l Seamless Round Pipe Stainless Steel Round Tube 1

Sch40 Aisi 304 316l Seamless Round Pipe Stainless Steel Round Tube 3

Applications:

316L: Widely used in corrosion-susceptible environment and some mechanical components those are difficult to make heat treatment after forming in more corrosive environment.

316Ti: Mainly used for industrial components.

Sch40 Aisi 304 316l Seamless Round Pipe Stainless Steel Round Tube 5
