201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil

201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil

  • High Light

    Cold Rolled Stainless Steel Coil ISG SGS

    ,

    2B 316L Stainless Steel Coil

    ,

    Cold Rolled Stainless Steel Coil 310S

  • Grade
    300 Series
  • Type
    Stainless Steel Coil
  • Tolerance
    ±1%
  • Steel Grade
    301L, 301, 316L, 316, 304, 304L
  • Surface Finish
    2B
  • Hardness
    Full Hard
  • Thickness
    0.4mm-1.2mm, 0.4mm-1.2mm
  • Standard
    ASTM, JIS
  • Place of Origin
    CHINA
  • Brand Name
    NADONG
  • Certification
    ISG SGS
  • Model Number
    201
  • Minimum Order Quantity
    1 Ton
  • Price
    $1200-$2000
  • Packaging Details
    According to customer needs
  • Delivery Time
    15 working days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    1000 ton per month

201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil

201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil



Stainless steel also contains varying amounts of Carbon, Silicon and Manganese. Other elements such as Nickel and Molybdenum may be added to impart other useful properties such as enhanced formability and increased corrosion resistance.Stainless steel is an alloy of Iron with a minimum of 10.5% Chromium. Chromium produces a thin layer of oxide on the surface of the steel known as the 'passive layer'. This prevents any further corrosion of the surface. Increasing the amount of Chromium gives an increased resistance to corrosion.



Specfications



Product Name
Stainless Steel Coil / Strip / Sheets
Standard
AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Material
201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321, 310S, 309S, 410, 410S,420, 430, 431, 440A, 904L, 2205, 2507, ect.


Thickness(mm)

Cold rolled:0.25mm-3.0mm
Hot rolled: 3.0mm-180mm
As Your Request
Width(mm)
45mm-2200mm, As Your Request
Technique
Hot rolled / cold rolled
Surface
2B,BA(bright annealed) NO.1 NO.2 NO.3 NO.4,2D, 4K, 6K, 8K HL(Hair Line), SB, Embossed,as your request
Coil ID
508-610mm or as per your request
Coil Weight
3~5 Tons or as per your request
Application
Furniture, doors, kitchen appliances, structural material, commercial use, structural use ,roofing,corrugated roofing, household appliance, industry, auto parts,cold roomse, etc.
Packing
Standard Sea-worthy Packing / As Your Request





Chemical Composition

Chemical composition and mechanical properties of stainless steel coils

Grade
Chemical Composition (%)
Mechanical Performance
C
Si
Mn
P
S
Ni
Cr
Mo
Hardness
201
≤0.15
≤1.00
5.5/7.5
≤0.060
≤0.03
3.5/5.5
16.0/18.0
-
HB≤241,HRB≤100, HV≤240
304
≤0.08
≤1.00
≤2.00
≤0.045
≤0.03
8.0/11.0
18.0/20.0
-
HB≤187,HRB≤90,HV≤200
316
≤0.08
≤1.00
≤2.00
≤0.045
≤0.03
10.0/14.0
16.0/18.0
2.0/3.0
HB≤187,HRB≤90,HV≤200
316L
≤0.03
≤1.00
≤2.00
≤0.045
≤0.03
10.0/14.0
16.0/18.0
2.0/3.0
HB≤187,HRB≤90,HV≤200
410
≤0.15
≤1.00
≤1.25
≤0.060
≤0.03
≤0.060
11.5/13.5
-
HB≤183, HRB≤88 HV≤200
430
≤0.12
≤1.00
≤1.25
≤0.040
≤0.03



-
16.0/18.0
-
HB≤183, HRB≤88 HV≤200





Surface Finished
Characteristics
Characteristics
NO.1
Finished by hot-rolling, smoother and pickling, characterized by white pickled surface.
Chemical industry equipment, Industrial tanks.
2B
Finished by anneal treatment, pickling after cold rolling, followed by skin pass line to more brighter and smoother surface.
General application medical instruments, Tableware.
BA
Bright anneal treatment after cold rolling.
Kichen utenstil, Kitchen ware,Architectural purpose.
NO.4(Satin)
Finished by incontinuous linear brushing
Architecture,industries,Escalators, Kitchen ware, Vehicles.
Hairline
Finished by continuous linear brushing
8K(mirror)
A mirror-like reflective surface by polishing with finer abrasives over 800 mesh.
Refletor, Mirror, Interior- Exterior decoration for building.





201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil 0

201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil 1

201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil 2

201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil 3

201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil 4







Applications:

316L: Widely used in corrosion-susceptible environment and some mechanical components those are difficult to make heat treatment after forming in more corrosive environment.

316Ti: Mainly used for industrial components.



201 Cold Rolled Stainless Steel Coil 310S 316L Stainless Steel Coil 5
