Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness

Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness

  • High Light

    316l Stainless Steel Metal Sheet

    ,

    0.3 mm stainless steel sheet

    ,

    Sa 240 Stainless Steel Metal Sheet 0.18mm

  • Grade
    300 Series
  • Thickness
    0.18-3mm
  • Width
    10mm-1280mm
  • Technique
    Cold Rolled ,Hot Rolled
  • Standard
    AiSi
  • Steel Grade
    301L, 301, 316L, 316, 304, 304L
  • Length
    Customerized
  • Application
    Decoration & Fabrication
  • Place of Origin
    China
  • Brand Name
    NADONG
  • Certification
    ISO SGS
  • Model Number
    316
  • Minimum Order Quantity
    1 Ton
  • Price
    $1200-$2000
  • Packaging Details
    According to customer needs
  • Delivery Time
    15 working days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    1000 ton per month

Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness

Asme Sa-240 316l Stainless Steel Plate



410S is a steel grade that improves the corrosion resistance and formability of 410 steel. 410F2 is a lead free-cutting steel that does not reduce the corrosion resistance of 410 steel. 410J1 is a high-strength steel grade that further improves the corrosion resistance of 410 steel and is used for turbine blades and high-temperature components.



Specfications

Type
Cold Drawn or Hot Rolled
Thickness
0.1-300mm
Width
1000, 1219, 1500, 2000, 2500, 3000mm etc.
Length
1000, 1500, 2438, 3000, 5800, 6000, 9000, 12000mm etc.
Standard
ASTM JIS AISI GB DIN EN
Surface Finished
BA, 2B, NO.1, NO.4, 4K, HL, 8K
Application
It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture,
and ship components.
It also applies to food and beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts,
springs, and screen mesh etc. .
Certification
CE, ISO, SGS, BV
Technique
Hot rolled or cold drawing
Edge
Mill Edge / Slit Edge
Quality
SGS Inspection
Grade(ASTM UNS)
201 202 301 304 304L 321 316 316L 317L 347H 309S 310S 904L S32205 2507 254SMOS 32760 253MA N08926 etc.
Grade (EN)
1.4301, 1.4307, 1.4541, 1.4401, 1.4404 ,1.4571, 1.4438, 1.4539, 1.4547, 1.4529, 1.4562, 1.4410, 1.4878, 1.4845, 1.4828, 1.4876,
2.4858, 2.4819
Price Terms
CIF CFR FOB EX-WORK
Export Packing
Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package
Supply Ability
5000 Ton/Tons per Month
Payment Terms
T/T L/C and Western Union etc.





Chemical Composition



Specification Grade Chemical Composition(wt%)
C Mn Ni Cr Mo Ti
ASTMJIS 316L/022Cr17Ni12Mo2 ≤0.03 ≤2.0 10.0-14.0 16.0-18.0 2.0-3.0 -
JIS SUS316L ≤0.03 ≤2.0 12.0-15.0 16.0-18.0 2.0-3.0 -
ASTMJIS 316Ti/SUS 316Ti ≤0.08 ≤2.0 10.0-14.0 16.0-18.0 2.0-3.0 5*(C+N)-0.7



Properties

Spec Grade Mechanical Property Physical Property

Y.S

(N/MM2)

T.S

(N/MM2)

EL

(%)

HRB

Specific Heat

(J/g℃)

Modulus of Elasticity (KN/mm2)
ASTM/GB 316L/022Cr17Ni12Mo2 ≥170 ≥485 ≥40 ≤95 0.5 193
JIS SUS316L ≥175 ≥480 ≥40 ≤90 193
ASTM 316Ti ≥205 ≥515 ≥40 ≤95 0.5 200



Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness 0

Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness 1

Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness 2

Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness 3



Applications:

316L: Widely used in corrosion-susceptible environment and some mechanical components those are difficult to make heat treatment after forming in more corrosive environment.



316Ti: Mainly used for industrial components.



Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness 4

Asme Sa 240 316l Stainless Steel Metal Sheet 0.18mm - 3mm Thickness 5
